d&b audiotechnik D90 Amplifier
Model Z2860.500
Price on Request
Availability: In Stock
- Authorized d&b audiotechnik Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
d&b audiotechnik D90 Amplifier
The d&b audiotechnik Z2860.500 D90 Amplifier delivers unparalleled sound quality and performance, increased system efficiency and power-saving features which place the D90 at the forefront of advanced amplifier technology. As well as providing maximum loudspeaker performance, it maintains lower internal temperatures at the highest output, ensuring long and reliable operation. By incorporating MILAN networking technology, its robust design allows seamless configuration for redundant system setups for audio signal transport, complemented by fallback capabilities for all inputs and device communication.
Why this product
Key Benefits
-
Maximum output power
-
4 x 5400/2700 W into 4/8 Ω
-
Maximum output voltage/current
-
210 Vpeak / 78 Apeak
-
Monitoring display, Color TFT touchscreen, 4.3" / 480 x 272 pixel
-
All current d&b loudspeaker setup
Technical details
Technical Specifications
System
- Delay setting
- 0.3 ms - 10 s
- Configurations
- current d&b loudspeakers
- Type
- Autosensing switch mode power supply with active Power Factor Correction (PFC)
Frequency
- Frequency generator
- Pink noise or Sine wave 10 Hz - 20 kHz
- Sampling frequency Digital AES/EBU
- 44.1, 48, 96, 192 kHz
Power
- POWER
- Mains power switch
- Mains connector
- powerCON®-HC
- Rated mains voltage
- 100 - 127 / 208 - 240 V, 50 - 60 Hz
Connectivity
- Latency analog and digital inputs
- 0.3 ms
- INPUT ANALOG (A1 - A4)
- 3 pin XLR female
- ANALOG LINK (A1 - A4)
- 3 pin XLR male
- INPUT DIGITAL (D1/2, D3/4)
- 3 pin XLR female AES3
- DIGITAL LINK (Output)
- 3 pin XLR male
- Speaker outputs A/B/C/D
- 4 x NL4
- 4 Channel output
- 1 x NL8
- ETHERNET
- 2 x RJ 45, 1 Gbit/100 Mbit Ethernet
Physical
- Dimensions (H x W x D)
- 2 RU x 19" x 512 mm/20.2"
- Weight
- 18.8 kg (41.5 lb)
General
- Function switches
- d&b loudspeaker specific circuits
- SCROLL/EDIT
- Digital rotary encoder
- Display
- Colour TFT touchscreen, 4.35"/480 x 272 pixel
More details
Additional Information
Specifications:
- Digital Signal Processing:
- Equalizer:
- 2 x 16-band
- PEQ/notch/shelving/asymmetric
- Equalizer:
- Controls and indicators:
- Connectors:
- Mix TOP/SUB / 2-Way Active output A/B and C/D: 2 x NL4
- Maximum output power per channel (THD+N < 0.5%, all channels driven): CF = 12 dB at 4 / 8 ohms: 4 x 5400/2700 W
- Power supply:
- Dimensions / weight:
