d&b audiotechnik U7N Loudspeaker
Model Z2015.000
Price on Request
Availability: In Stock
- Authorized d&b audiotechnik Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
d&b audiotechnik U7N Loudspeaker Networked 2-way Compact Dipole Loudspeaker
The d&b audiotechnik U7 has dual 8" bipole drivers paired with a 1.26" compression driver mounted on a rotatable 80° × 55° horn to provide directivity control and efficiency.
The loudspeaker features advanced horn geometry and bass-reflex ports to extend LF response to 55 Hz (−5 dB) while maintaining consistent 80° horizontal dispersion and 55° vertical directivity from 500 Hz upward. It also includes tool-free horn rotation enabling quick deployment adjustments.
The loudspeaker features a hybrid power topology, running on AC, PoE++, or both simultaneously, with single‑cable operation carrying power, signal, control, and monitoring, while dual‑cable redundancy (2× PoE++ + 2× Milan) supports mission‑critical installations and ensures compatibility with the DN2 Milan PoE++ switch or equivalent third‑party PoE++ hardware.
Why this product
Key Benefits
-
Components 2 x 8" / 1.26"
-
Dispersion 80° x 55° rotatable
-
SPLmax 136 dB
-
Weight 19.4 kg / 42.8 lb
Technical details
Technical Specifications
System
- Components
- 2 x 8" driver with neodymium magnet, 1 x 1.26" exit HF compression driver with 2.4" coil, Rotatable CD horn
- Equalizer
- 2 user definable 16-band equalizer
- Delay
- 1.1 ms to 1 sec.
Frequency
- Frequency response (-5 dB standard)
- 55 Hz - 18 kHz
- Frequency response (-5 dB CUT mode)
- 105 Hz - 18 kHz
- Frequency generator
- Pink noise or sine wave 10 Hz to 20 kHz
Performance & Coverage
- Max. sound pressure
- 136 dB
- Nominal dispersion angle (h x v)
- 80° x 55°
Power
- Mains connector
- powerCON TRUE1 TOP In and Thru
- Power supply
- Switched mode power supply with automatic mains range selection and active Power Factor Correction (PFC).
- Rated mains voltage
- 100 - 240 V, 50 - 60 Hz
Connectivity
- Latency analog input
- 1.1 ms
- INPUT ANALOG
- 3 pin XLR female
- ANALOG LINK
- 3pin XLR male, parallel to input
- Network Connection
- 2 x RJ 45 (etherCon)
- Network Switch
- integrated 2-port, 100 Mbit/1 Gbit
Physical
- Dimensions (h x w x d)
- 24 x 10.6 x 14", 611 x 268 x 355 mm
- Weight
- 42,8 lb, 19.4 kg
General
- ETH1/PRI
- Milan, Remote control via R1 star topology
- ETH2/SEC
- Milan redundancy only, no remote control star topology
More details
Additional Information
Specifications:
- Frequency response (-10 dB standard, IEC60268): 50 Hz - 20kHz
- Frequency response (-10 dB CUT mode, IEC60268): 75 Hz - 20kHz
- MILAN INPUT: 1 stream with up to 8 channels @ 48/96 kHz
