JBL Base Plate for SRX910LA
Model SRX910LA-BP
Price on Request
Availability: In Stock
- Authorized JBL Professional Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
JBL SRX910LA-BP Base Plate for SRX910LA
The SRX910LA Base Plate is a universal adapter frame that enables SRX910LA arrays to be ground stacked on top of compatible subwoofers or support structures such as stages, scaffolding, or carts. Using the included M20 screw, the SRX910LA BP connects to any supported subwoofer equipped with a standard M20 pole mount adapter, such as the SRX928S. The rear angle selection bar allows for angles ranging from -15 to +5 degrees. The three included M10 through-holes can be used to permanently attach an SRX910LA array to other support structures. Configurations and load conditions for using the SRX910LA BP can be obtained using JBL Line Array Calculator 3 software.
Why this product
Key Benefits
-
Enables ground stacking SRX910LA arrays
-
Allows attaching arrays to subwoofers
-
Universal M20 threaded pole mount
-
Angle range: -15 degrees to +5 degrees
-
Support for up to (4) SRX910LA
Technical details
Technical Specifications
Compatibility
- Safe Limit
- (2) SRX910LA
Build
- Construction
- High-grade steel with anti-corrosion coating
- Finish
- Black powder coat
Dimensions
- Dimensions (H x W x D)
- 75 mm x 683 mm x 540 mm (2.9 in x 26.9 in x 21.3 in
- Net Weight
- 6.0 kg (13 lbs)
General
- Maximum
- (4) SRX910LA
More details
Additional Information
Specifications:
- Mechanical Limits:
- Shipping
