LG 84TR3B 84-inch 4K Interactive Digital Board
Model lg-84tr3bMPN 84TR3B
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Screen: 84-inch 4K UHD interactive display
- Native resolution: 3840 × 2160
- Touch: IR spread, up to 10 points
- Published brightness basis: 350 cd/m² typical module; 300 cd/m² with protection glass
- Platform: Legacy external-host interactive workflow; confirm current host, driver and application support
- Authorized LG Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the LG 84TR3B?
The LG 84TR3B is a 84-inch 4K UHD interactive display for shared annotation, presentations and collaborative sessions. Its IR spread touch system supports up to 10 simultaneous touch points with a compatible host. Plan the host connection, current software support, viewing height and VSYS mounting arrangement as a complete room system. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
A 84-inch interactive board with 3840 × 2160 native resolution and an integrated touch surface. Legacy external-host interactive workflow; confirm current host, driver and application support. A compatible host uses video plus touch USB when required; an HDMI picture alone does not return touch control. Optional PCs and conferencing equipment must be specified separately.
- Touch: IR spread, up to 10 points.
- Platform: Legacy external-host interactive workflow; confirm current host, driver and application support.
Use cases
Applications
-
84-inch shared annotation and presentation spaces
-
Training and education rooms with verified host/software compatibility
-
Legacy interactive board replacements with touch USB and fixing checks
Technical details
Technical Specifications
Display
- Screen
- 84-inch 4K UHD interactive display
- Native resolution
- 3840 × 2160
- Published brightness basis
- 350 cd/m² typical module; 300 cd/m² with protection glass
- Screen
- 84-inch 4K UHD interactive display.
- Native resolution
- 3840 × 2160.
- Published brightness basis
- 350 cd/m² typical module; 300 cd/m² with protection glass.
Touch
- Touch
- IR spread, up to 10 points
- Touch host connection
- USB touch connection alongside the selected video source; check host drivers
System & Software
- Platform
- Legacy external-host interactive workflow; confirm current host, driver and application support
Audio & Camera
- Audio
- External-speaker output; optional SP-2100 speakers are separate
Connectivity
- Video input
- Two HDMI, DisplayPort and DVI-D
Physical & Mounting
- VESA mounting
- 600 × 400 mm
- Reference panel weight
- 104 kg
- Reference dimensions (W × H × D)
- 1951.2 × 1137.2 × 111.9 mm
Model & Identification
- Model
- 84TR3B
- Manufacturer part number
- 84TR3B
In the box
What's Included
-
One LG 84TR3B display
-
Power cord
-
Remote control with two batteries
-
IR/light sensor receiver
-
USB 2.0 cable
-
HDMI 2.0 cable
-
DisplayPort cable
-
Two cable ties
-
Two touch pens
-
Pen tray
-
Two eye-bolt assemblies
-
Screw package
-
ESG documentation
Installation
Installation & Mounting
Recommended Compatible Equipment
VSYS VS01A-69F Fixed TV Mount. Optional VSYS fixed wall mount. Its 60–120-inch, 120 kg rating accommodates the 84-inch, 104 kg reference board. Check the 600 × 400 mm pattern, screw engagement, complete load, wall structure and suitability for touch interaction.
VSYS VTLX16-69FW TV Cart. Optional VSYS mobile floor stand. Its 55–100-inch, 120 kg rating and listed 600 × 400 mm pattern cover this reference board. Verify the complete load, touch-use stability, allowed orientation, working height, brakes and floor conditions.
Installation
Match 600 × 400 mm VESA and the 104 kg reference panel weight to the VSYS support. Allow for attached equipment and touch interaction loads, and confirm the structural fixings, stand stability, height, orientation, ventilation and lifting route. Check the exact regional suffix, host drivers, touch-point support and application availability for this legacy model. An OPS slot or kit is not an included Windows PC. Cameras, conferencing software, room microphones and mounts are separate.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your 84TR3B quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
