MAXHUB C55FA 55-inch V5 Classic Interactive Display

Model C55FA

Price on Request

Availability: Contact Us

WhatsApp an Expert

Call an Expert: +971 56 498 8088 info@corporateav.ae

  • Display: 55-inch VA, 3840 × 2160 UHD at 60 Hz
  • Touch: 20-point infrared touch; confirm operating-system support
  • Brightness: 350 cd/m² typical in the V5 reference specification
  • Camera: Built-in 12 MP camera in the upper bezel
  • Microphones: Six-microphone array; actual performance depends on room acoustics
Boardrooms & Meeting Rooms Part of our complete AV solutions Explore Solutions
MAXHUB C55FA 55-inch V5 Classic Interactive Display
  • Authorized MAXHUB Reseller
  • Manufacturer Warranty
  • Fast UAE Delivery
  • Expert Project Support
Delivery, Warranty, Returns and Installation
Delivery
Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
Warranty
Manufacturer Warranty with Local UAE Support where applicable.
Returns
B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
Installation
Site Surveys, System Design and Professional Installation are available across the UAE.
Call

Product details

Overview

What is the MAXHUB C55FA?

The MAXHUB C55FA V5 Classic is a 55-inch 4K interactive panel for compact meeting rooms. It combines touch writing, a built-in camera and room audio with separately specified computing options, making the supplied module and software configuration an important part of the purchase. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.

A 55-inch interactive panel from the V5 Classic generation, intended for shared presentations, annotation and remote collaboration with suitable computing hardware.

  • Camera: Built-in 12 MP camera in the upper bezel.
  • Microphones: Six-microphone array; actual performance depends on room acoustics.

Use cases

Applications

  • Meeting-room presentations and annotation

  • Training and collaborative workshops

  • Video meetings with a verified host and application configuration

Technical details

Technical Specifications

Display

Brightness
350 cd/m² typical in the V5 reference specification
Brightness
350 cd/m² typical in the V5 reference specification.

Touch

Touch
20-point infrared touch; confirm operating-system support
Touch
20-point infrared touch; confirm operating-system support.

Audio & Camera

Camera
Built-in 12 MP camera in the upper bezel
Microphones
Six-microphone array; actual performance depends on room acoustics
Audio
2.1-channel system: two 10 W speakers and 20 W subwoofer

Connectivity

Panel connections
One HDMI input, two USB-C ports, USB-A, touch return, audio output and RS232

Physical & Mounting

Dimensions (W × H × D)
1263 × 777 × 87 mm
Net panel weight
28.15 kg in the manufacturer reference
VESA mounting
400 × 200 mm

Included & Optional Accessories

Optional computing
MT51-series Windows PC module or SA08 Android module; supplied bundle must be confirmed

Model & Identification

Model
C55FA
Manufacturer part number
C55FA

General

Display
55-inch VA, 3840 × 2160 UHD at 60 Hz
Environment
Indoor, 0–40°C
Display
55-inch VA, 3840 × 2160 UHD at 60 Hz.

In the box

What's Included

  • 55-inch MAXHUB C55FA V5 Classic panel

  • 3 m power cable

  • Two styluses

  • Manufacturer wall mount in the global reference pack; confirm regional inclusion

  • WiFi module in the global series reference; confirm regional inclusion

  • Quick guide

  • Warranty card

Installation

Installation & Mounting

Recommended Compatible Equipment

VSYS VS01E-44F Fixed TV Mount. VSYS wall-mount option covering the reference screen size, panel weight and VESA pattern. Check whether the supplied regional pack already includes a suitable manufacturer bracket and confirm any VSYS alternative against the actual installation.

VSYS VTLS12-46TW TV Cart. VSYS floor-stand option covering the screen range, reference panel load and listed VESA pattern. Add the computing module and accessory weights, and confirm stability during touch use; trolley is separate.

Installation

Check the actual regional panel and module configuration, 400 × 200 mm VESA pattern, 28.15 kg reference panel weight and full accessory load. Confirm legacy module availability, firmware, meeting-app compatibility, licensing and IT requirements. Assess wall anchors, viewing and touch height, rear access, ventilation, cable movement and trolley stability.

Ownership and support

Ownership & Support

Warranty

Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.

Support

Share your C55FA quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.

Complete your solution

Recommended Accessories

Expert FAQs

What is the MAXHUB C55FA used for?

The MAXHUB C55FA V5 Classic is a 55-inch 4K interactive panel for compact meeting rooms. It combines touch writing, a built-in camera and room audio with separately specified computing options, making the supplied module and software configuration an important part of the purchase.

Is C55FA a current-generation Android EDLA panel?

It is a V5 Classic-generation product. The referenced computing options are MT51-series Windows and SA08 Android modules, specified separately. Do not assume the specifications or Google certification of a newer MAXHUB education panel.

Does C55FA need another camera or speaker amplifier?

The panel includes a 12 MP camera, six-microphone array and powered speaker system. Its built-in speakers do not require an external speaker amplifier. A suitable computing module or host, supported software and network are still needed for video calls.

Which equipment should I consider with C55FA?

VSYS VS01E-44F Fixed TV Mount. VSYS wall-mount option covering the reference screen size, panel weight and VESA pattern. Check whether the supplied regional pack already includes a suitable manufacturer bracket and confirm any VSYS alternative against the actual installation.

VSYS VTLS12-46TW TV Cart. VSYS floor-stand option covering the screen range, reference panel load and listed VESA pattern. Add the computing module and accessory weights, and confirm stability during touch use; trolley is separate.

What is included with C55FA?

55-inch MAXHUB C55FA V5 Classic panel; 3 m power cable; Two styluses; Manufacturer wall mount in the global reference pack; confirm regional inclusion; WiFi module in the global series reference; confirm regional inclusion; Quick guide; Warranty card. Confirm the exact regional pack on the quotation.

What should I check before installing C55FA?

Check the actual regional panel and module configuration, 400 × 200 mm VESA pattern, 28.15 kg reference panel weight and full accessory load. Confirm legacy module availability, firmware, meeting-app compatibility, licensing and IT requirements. Assess wall anchors, viewing and touch height, rear access, ventilation, cable movement and trolley stability.

Can Corporate AV help specify C55FA for a UAE project?

Share your C55FA quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.

How can I request a MAXHUB C55FA quotation in the UAE?

Contact Corporate AV about MAXHUB C55FA. Call +971 56 498 8088, WhatsApp our team or email info@corporateav.ae. Share the quantity, connected equipment and project location so we can confirm availability, lead time and the required scope.
