MAXHUB C7530 75-inch V6 Classic Interactive Display
Model C7530
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Display: 75-inch 3840 × 2160 UHD at 60 Hz
- Touch: 20-point infrared touch; operating-system support must be checked
- Brightness: 350 cd/m² typical
- Duty and orientation: 16/7; landscape
- Panel type: VA
- Authorized MAXHUB Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the MAXHUB C7530?
The MAXHUB C7530 V6 Classic combines a 75-inch 4K touch display with built-in camera, microphones and room speakers for larger meeting and training rooms. It brings shared annotation and remote-meeting hardware together, with the required computing module and licences specified as part of the complete system. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
A 75-inch interactive collaboration panel in the V6 Classic range, designed for presentations, whiteboarding and video meetings with the appropriate computing configuration.
- Touch: 20-point infrared touch; operating-system support must be checked.
- Panel type: VA.
Use cases
Applications
-
Meeting-room whiteboarding and annotation
-
Remote meetings with the specified computing module
-
Training and shared presentation work
Technical details
Technical Specifications
Display
- Brightness
- 350 cd/m² typical
- Panel type
- VA
- Brightness
- 350 cd/m² typical.
Touch
- Touch
- 20-point infrared touch; operating-system support must be checked
Audio & Camera
- Camera
- Built-in single 48 MP camera; automatic framing and speaker tracking
- Microphones
- Eight-microphone array; room acoustics affect pickup
- Audio
- 2.1-channel system: two 10 W speakers and a 20 W subwoofer
Connectivity
- Connections
- HDMI, USB-A, USB touch return, USB-C, audio output and RS232
- Wireless
- SI06 WiFi adapter in the published package
Physical & Mounting
- Duty and orientation
- 16/7; landscape
- Dimensions (W × H × D)
- 1709 × 1026 × 87 mm
- Net panel weight
- 48.3 kg; confirm complete installed configuration
- VESA mounting
- 800 × 400 mm
- Duty and orientation
- 16/7; landscape.
Model & Identification
- Model
- C7530
- Manufacturer part number
- C7530
General
- Display
- 75-inch 3840 × 2160 UHD at 60 Hz
- Computing
- MT61 PC module platform; confirm module, OS and licences in the quoted bundle
- Display
- 75-inch 3840 × 2160 UHD at 60 Hz.
In the box
What's Included
-
75-inch MAXHUB C7530 V6 Classic panel
-
Regional power cord
-
WiFi adapter
-
Two passive styluses
-
Manufacturer wall mount
-
1.8 m USB-C cable
Installation
Installation & Mounting
Recommended Compatible Equipment
VSYS VS01A-69F Fixed TV Mount. VSYS wall-mount alternative covering the reference screen range, panel weight and VESA pattern. The standard manufacturer pack lists a wall mount, so confirm whether a VSYS replacement is required and check structural fixing and rear access.
VSYS VTLX16-69FW TV Cart. VSYS floor-stand option with a screen range, load capacity and listed VESA pattern covering this panel. Check total weight with the PC and accessories, cable slack and touch-use stability; trolley is separate.
Installation
Match the 800 × 400 mm VESA pattern and 48.3 kg reference panel weight to the mount and total accessory load. Confirm supplied PC module, licences, firmware, application support and regional accessory pack. Plan indoor landscape installation, wall anchors, touch reach, rear clearance, cable movement and trolley stability.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your C7530 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
