MAXHUB C86FA 86-inch V5 Classic Interactive Display
Model C86FA
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Display: 86-inch VA, 3840 × 2160 UHD at 60 Hz
- Touch: 20-point infrared touch; confirm operating-system support
- Brightness: 350 cd/m² typical in the V5 reference specification
- Camera: Built-in 12 MP camera in the upper bezel
- Microphones: Six-microphone array; actual performance depends on room acoustics
- Authorized MAXHUB Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the MAXHUB C86FA?
The MAXHUB C86FA V5 Classic is a 86-inch 4K interactive panel for large presentation and collaboration spaces. It combines touch writing, a built-in camera and room audio with separately specified computing options, making the supplied module and software configuration an important part of the purchase. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
A 86-inch interactive panel from the V5 Classic generation, intended for shared presentations, annotation and remote collaboration with suitable computing hardware.
- Camera: Built-in 12 MP camera in the upper bezel.
- Microphones: Six-microphone array; actual performance depends on room acoustics.
Use cases
Applications
-
Meeting-room presentations and annotation
-
Training and collaborative workshops
-
Video meetings with a verified host and application configuration
Technical details
Technical Specifications
Display
- Brightness
- 350 cd/m² typical in the V5 reference specification
- Brightness
- 350 cd/m² typical in the V5 reference specification.
Touch
- Touch
- 20-point infrared touch; confirm operating-system support
- Touch
- 20-point infrared touch; confirm operating-system support.
Audio & Camera
- Camera
- Built-in 12 MP camera in the upper bezel
- Microphones
- Six-microphone array; actual performance depends on room acoustics
- Audio
- 2.1-channel system: two 10 W speakers and 20 W subwoofer
Connectivity
- Panel connections
- One HDMI input, two USB-C ports, USB-A, touch return, audio output and RS232
Physical & Mounting
- Dimensions (W × H × D)
- 1957 × 1166 × 86 mm
- Net panel weight
- 65.55 kg in the manufacturer reference
- VESA mounting
- 800 × 600 mm
Included & Optional Accessories
- Optional computing
- MT51-series Windows PC module or SA08 Android module; supplied bundle must be confirmed
Model & Identification
- Model
- C86FA
- Manufacturer part number
- C86FA
General
- Display
- 86-inch VA, 3840 × 2160 UHD at 60 Hz
- Environment
- Indoor, 0–40°C
- Display
- 86-inch VA, 3840 × 2160 UHD at 60 Hz.
In the box
What's Included
-
86-inch MAXHUB C86FA V5 Classic panel
-
3 m power cable
-
Two styluses
-
Manufacturer wall mount in the global reference pack; confirm regional inclusion
-
WiFi module in the global series reference; confirm regional inclusion
-
Quick guide
-
Warranty card
Installation
Installation & Mounting
Recommended Compatible Equipment
VSYS VS01A-69F Fixed TV Mount. VSYS wall-mount option covering the reference screen size, panel weight and VESA pattern. Check whether the supplied regional pack already includes a suitable manufacturer bracket and confirm any VSYS alternative against the actual installation.
VSYS VTLX16-69FW TV Cart. VSYS floor-stand option covering the screen range, reference panel load and listed VESA pattern. Add the computing module and accessory weights, and confirm stability during touch use; trolley is separate.
Installation
Check the actual regional panel and module configuration, 800 × 600 mm VESA pattern, 65.55 kg reference panel weight and full accessory load. Confirm legacy module availability, firmware, meeting-app compatibility, licensing and IT requirements. Assess wall anchors, viewing and touch height, rear access, ventilation, cable movement and trolley stability.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your C86FA quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
