MAXHUB UC BM45 Wired Conference Speakerphone

Model UC BM45

Price on Request

Availability: Contact Us

WhatsApp an Expert

Call an Expert: +971 56 498 8088 info@corporateav.ae

  • Microphones: Eight-microphone array
  • Pickup reference: Best at 4 m; maximum 8 m under manufacturer conditions
  • Audio processing: Full duplex, echo cancellation, automatic gain and AI noise reduction
  • Speaker: 5 W maximum output
  • Connections: USB-C, RJ45 PoE input and RJ45 cascade output
Video Conferencing & Hybrid Workspaces Part of our complete AV solutions Explore Solutions
MAXHUB UC BM45 Wired Conference Speakerphone
  • Authorized MAXHUB Reseller
  • Manufacturer Warranty
  • Fast UAE Delivery
  • Expert Project Support
Delivery, Warranty, Returns and Installation
Delivery
Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
Warranty
Manufacturer Warranty with Local UAE Support where applicable.
Returns
B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
Installation
Site Surveys, System Design and Professional Installation are available across the UAE.
Call

Product details

Overview

What is the MAXHUB UC BM45?

The MAXHUB UC BM45 is a wired meeting-room speakerphone for teams that need table-level speech pickup and playback. Its microphone array and full-duplex processing support discussion, while compatible cascading lets an installer extend coverage across a larger table. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.

A powered conference speakerphone with microphones and a loudspeaker, not a passive installation speaker.

Why this product

Key Benefits

  • Microphones

    Eight-microphone array.

  • Pickup reference

    Best at 4 m; maximum 8 m under manufacturer conditions.

  • Audio processing

    Full duplex, echo cancellation, automatic gain and AI noise reduction.

  • Connections

    USB-C, RJ45 PoE input and RJ45 cascade output.

Use cases

Applications

  • Meeting-room table audio

  • Longer tables using a designed BM45 cascade

  • Compatible MAXHUB XBoard V7 room installations

Technical details

Technical Specifications

Audio

Microphones
Eight-microphone array
Pickup reference
Best at 4 m; maximum 8 m under manufacturer conditions
Audio processing
Full duplex, echo cancellation, automatic gain and AI noise reduction
Speaker
5 W maximum output
Speaker
5 W maximum output.

Connectivity

Connections
USB-C, RJ45 PoE input and RJ45 cascade output
Expansion
Up to six UC BM45 units in a supported cascade

Physical & Power

Power
PoE or specified 54 V adapter arrangement; verify the full cascade design
Size and weight
122 mm diameter × 65 mm; 472 g

Model & Identification

Model
UC BM45
Manufacturer part number
UC BM45

In the box

What's Included

  • MAXHUB UC BM45 speakerphone

  • Table bracket

  • Power adapter

  • 3 m USB-C to USB-A cable

  • 3 m Ethernet cable

Installation

Installation & Mounting

Recommended Compatible Equipment

MAXHUB V6550 65-inch XBoard V7 Interactive Display. MAXHUB V6550 XBoard V7 has a documented microphone-input workflow for UC BM45. Confirm the exact supported connection, firmware and power arrangement, including the XBoard PC configuration.

Installation

Check the USB host or compatible MAXHUB V7 microphone-input arrangement, power budget, cable category and cascade topology. RJ45 ports have specific PoE and audio functions; follow the manufacturer diagram rather than treating every port as ordinary Ethernet. Assess room acoustics and microphone placement.

Ownership and support

Ownership & Support

Warranty

Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.

Support

Share your UC BM45 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.

Complete your solution

Recommended Accessories

Expert FAQs

What is the MAXHUB UC BM45 used for?

The MAXHUB UC BM45 is a wired meeting-room speakerphone for teams that need table-level speech pickup and playback. Its microphone array and full-duplex processing support discussion, while compatible cascading lets an installer extend coverage across a larger table.

Does UC BM45 need a separate amplifier?

No. Its powered speakerphone design contains the speaker and microphones. Specify the correct power and host connection instead of a passive-speaker amplifier.

Can I extend BM45 coverage with more units?

The manufacturer supports cascading up to six UC BM45 units. Cable selection, port direction, power and host topology must follow the supported design; do not mix arbitrary speakerphones in the chain.

Which equipment should I consider with UC BM45?

MAXHUB V6550 65-inch XBoard V7 Interactive Display. MAXHUB V6550 XBoard V7 has a documented microphone-input workflow for UC BM45. Confirm the exact supported connection, firmware and power arrangement, including the XBoard PC configuration.

What is included with UC BM45?

MAXHUB UC BM45 speakerphone; Table bracket; Power adapter; 3 m USB-C to USB-A cable; 3 m Ethernet cable. Confirm the exact regional pack on the quotation.

What should I check before installing UC BM45?

Check the USB host or compatible MAXHUB V7 microphone-input arrangement, power budget, cable category and cascade topology. RJ45 ports have specific PoE and audio functions; follow the manufacturer diagram rather than treating every port as ordinary Ethernet. Assess room acoustics and microphone placement.

Can Corporate AV help specify UC BM45 for a UAE project?

Share your UC BM45 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
