MAXHUB UW92NA 92-inch 21:9 5K Ultrawide Display
Model UW92NA
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Display: 92-inch VA, 5120 × 2160 at 60 Hz
- Aspect ratio: 21:9 ultrawide
- Brightness: 500 cd/m² typical and 600 cd/m² maximum in the detailed datasheet
- Duty and orientation: 24/7; landscape or portrait following the installation guide
- Platform: Android 13, 8 GB RAM and 64 GB storage
- Authorized MAXHUB Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the MAXHUB UW92NA?
The MAXHUB UW92NA provides a 92-inch ultrawide 5K canvas for meeting layouts, wide-format presentations and business information. Its 21:9 shape creates more horizontal space than a standard 16:9 display, helping teams arrange content and meeting participants across a single large screen. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
A 92-inch, 21:9 commercial display with a 5120 × 2160 panel and built-in meeting and sharing software.
Why this product
Key Benefits
-
Brightness
500 cd/m² typical and 600 cd/m² maximum in the detailed datasheet.
-
Duty and orientation
24/7; landscape or portrait following the installation guide.
-
Platform
Android 13, 8 GB RAM and 64 GB storage.
Use cases
Applications
-
Ultrawide meeting-room content layouts
-
Wide-format presentations and dashboards
-
Indoor business information displays
Technical details
Technical Specifications
Display
- Aspect ratio
- 21:9 ultrawide
- Brightness
- 500 cd/m² typical and 600 cd/m² maximum in the detailed datasheet
- Aspect ratio
- 21:9 ultrawide.
System & Software
- Platform
- Android 13, 8 GB RAM and 64 GB storage
- Software
- MAXHUB Meeting OS, Share and Pivot device management
Audio & Camera
- Audio
- Two 20 W speakers and 20 W subwoofer
Connectivity
- Video inputs
- Four HDMI inputs, including one 5K-capable input, plus DisplayPort supporting 5K at 60 Hz
- USB-C
- Video, audio, network sharing and up to 100 W PD with compatible equipment
Physical & Mounting
- Duty and orientation
- 24/7; landscape or portrait following the installation guide
- Size and weight
- 2182 × 944 × 85 mm; 43.40 kg net
- VESA mounting
- 800 × 600 mm
Model & Identification
- Model
- UW92NA
- Manufacturer part number
- UW92NA
General
- Display
- 92-inch VA, 5120 × 2160 at 60 Hz
- Operating environment
- Indoor, 0–40°C
- Display
- 92-inch VA, 5120 × 2160 at 60 Hz.
In the box
What's Included
-
92-inch MAXHUB UW92NA display
-
3 m power cord
-
3 m HDMI cable
-
Remote control
-
WIB9080A manufacturer wall mount
-
SI07B wireless adapter
Installation
Installation & Mounting
Recommended Compatible Equipment
VSYS VS01A-69F Fixed TV Mount. VSYS wall-mount alternative supporting the 92-inch screen, 43.40 kg net panel and 800 × 600 mm fixings. A manufacturer wall mount is listed in the pack, so confirm whether a VSYS alternative is needed.
VSYS VTLX16-69FW TV Cart. VSYS floor-stand option covering the display's screen size, weight and 800 × 600 mm VESA pattern. Check its wide-panel stability, complete accessory load, cable slack and movement route.
Installation
Check the 800 × 600 mm VESA pattern, 43.40 kg panel weight and full installed load. Plan for the 2182 mm panel width, access route, viewing distance, structure, connectors and ventilation. A compatible source and input are required for native 5120 × 2160 at 60 Hz. Confirm touch requirements and the supplied configuration instead of assuming every commercial display is an interactive whiteboard.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your UW92NA quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
