MAXHUB XBar U50 Dual-Camera USB Video Bar
Model Xbar U50MPN XBar U50
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Camera system: Two 50 MP camera sensors
- View and zoom: 130° diagonal wide view; 6× digital zoom
- Video output: Up to 4K in supported H.264/MJPEG modes; other formats have lower limits
- Microphones: 12-microphone array
- Speaker output: Two 15 W speakers, maximum rating
- Authorized MAXHUB Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the MAXHUB XBar U50?
The MAXHUB XBar U50 is a dual-camera USB video bar for a meeting room built around a supported host computer. It combines automatic framing and microphone processing with powered stereo speakers, keeping front-of-room video and audio in one device. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
A USB conferencing bar that uses an external host to run the meeting application.
Why this product
Key Benefits
-
Camera system
Two 50 MP camera sensors.
-
Video output
Up to 4K in supported H.264/MJPEG modes; other formats have lower limits.
-
Speaker output
Two 15 W speakers, maximum rating.
Use cases
Applications
-
USB meeting-room AV upgrades
-
Computer-based team conferencing
-
Rooms requiring integrated front-of-room cameras and audio
Technical details
Technical Specifications
Camera
- Camera system
- Two 50 MP camera sensors
- View and zoom
- 130° diagonal wide view; 6× digital zoom
- Video output
- Up to 4K in supported H.264/MJPEG modes; other formats have lower limits
- View and zoom
- 130° diagonal wide view; 6× digital zoom.
Audio
- Microphones
- 12-microphone array
- Speaker output
- Two 15 W speakers, maximum rating
- Microphones
- 12-microphone array.
Connectivity
- Host connection
- USB 3.0 Type-B
- Expansion port
- RJ45 for supported expansion microphones; not a general network-video port
Physical & Power
- Power
- 19 V DC
- Size and weight
- 650.8 × 76.6 × 95.7 mm; 2.68 kg net
Model & Identification
- Model
- XBar U50
- Manufacturer part number
- XBar U50
General
- Privacy
- Electric automatic lens shutter
In the box
What's Included
-
MAXHUB XBar U50 USB video bar
-
Power adapter
-
1.5 m AC cable
-
3 m USB-B to USB-A cable
-
Remote control
-
Mounting components
-
Positioning card
Installation
Installation & Mounting
Recommended Compatible Equipment
MAXHUB ND55CMA 55-inch 4K Commercial Display. MAXHUB ND55CMA is a display option for the external host computer. U50 supplies USB camera and audio to that host; the host's video output connects to the display.
Installation
Specify the host PC, conferencing app, display connection, bar position and correct power adapter. Check USB video format support, firmware and any approved expansion microphones. Keep the expansion RJ45 connection distinct from ordinary Ethernet and IP camera ports.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your XBar U50 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
