Biamp

Biamp D-VOL120

Model 129514MPN D-VOL120

Price on Request

Availability: Contact Us

WhatsApp an Expert

Call an Expert: +971 56 498 8088 info@corporateav.ae

  • Speaker-line voltage: 70 V
  • Maximum connected load: 120 W
  • Attenuation: Eleven steps plus off
  • Priority override: 24 V relay
  • Connector: Six-pole Euroblock
Biamp D-VOL120
  • Authorized Biamp Reseller
  • Manufacturer Warranty
  • Fast UAE Delivery
  • Expert Project Support
Delivery, Warranty, Returns and Installation
Delivery
Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
Warranty
Manufacturer Warranty with Local UAE Support where applicable.
Returns
B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
Installation
Site Surveys, System Design and Professional Installation are available across the UAE.
Call

Product details

Overview

What is the Biamp D-VOL120?

The Biamp D-VOL120 is a Decora-style 70 V speaker-line volume controller rated for a maximum 120 W load. It provides stepped local attenuation and a 24 V priority relay that can bypass the local volume setting when correctly wired. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.

The Biamp D-VOL120 is a Decora-style 70 V speaker-line volume controller rated for a maximum 120 W load. It provides stepped local attenuation and a 24 V priority relay that can bypass the local volume setting when correctly wired.

  • Attenuation: Eleven steps plus off.
  • Connector: Six-pole Euroblock.

Use cases

Applications

  • Retail and hospitality audio

  • Commercial room and zone audio

Technical details

Technical Specifications

Power

Speaker-line voltage
70 V
Speaker-line voltage
70 V.

Physical & Mounting

Dimensions W × H × D
70 × 115 × 50 mm

Model & Identification

Model
D-VOL120
Manufacturer part number
D-VOL120

General

Maximum connected load
120 W
Attenuation
Eleven steps plus off
Priority override
24 V relay
Connector
Six-pole Euroblock
Maximum connected load
120 W.
Priority override
24 V relay.

In the box

What's Included

  • One Biamp D-VOL120; confirm the connector, mounting and regional accessory pack on the quotation

Installation

Installation & Mounting

Recommended Compatible Equipment

Biamp MA120 Rackmount Mixing Amplifier. Use the 70 V output and documented 24 V priority arrangement; calculate the downstream speaker load.

Biamp KUBO3T-W 3" Cabinet Loudspeaker | White. Use matching 70 V taps and keep the total connected load within the controller's rating.

Installation

Use only the specified 70 V speaker line. Calculate the full downstream speaker-tap load, confirm wall-box depth and connect any priority override according to the exact model's manual.

Ownership and support

Ownership & Support

Warranty

Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.

Support

Share your D-VOL120 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.

Complete your solution

Recommended Accessories

Expert FAQs

What is the Biamp D-VOL120 used for?

The Biamp D-VOL120 is a Decora-style 70 V speaker-line volume controller rated for a maximum 120 W load. It provides stepped local attenuation and a 24 V priority relay that can bypass the local volume setting when correctly wired.

Can priority audio pass when local volume is off?

The 24 V priority relay can bypass the volume setting when the amplifier's priority output and controller are correctly wired and commissioned.

Is D-VOL120 a 100 V controller?

No. Biamp specifies this model for 70 V speaker lines. Do not select it for a 100 V design.

Which equipment should I consider with D-VOL120?

Biamp MA120 Rackmount Mixing Amplifier. Use the 70 V output and documented 24 V priority arrangement; calculate the downstream speaker load.

Biamp KUBO3T-W 3" Cabinet Loudspeaker | White. Use matching 70 V taps and keep the total connected load within the controller's rating.

What is included with D-VOL120?

One Biamp D-VOL120; confirm the connector, mounting and regional accessory pack on the quotation. Confirm the exact regional pack on the quotation.

What should I check before installing D-VOL120?

Use only the specified 70 V speaker line. Calculate the full downstream speaker-tap load, confirm wall-box depth and connect any priority override according to the exact model's manual.

Can Corporate AV help specify D-VOL120 for a UAE project?

Share your D-VOL120 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.

How can I request a Biamp D-VOL120 quotation in the UAE?

Contact Corporate AV about Biamp D-VOL120. Call +971 56 498 8088, WhatsApp our team or email info@corporateav.ae. Share the quantity, connected equipment and project location so we can confirm availability, lead time and the required scope.
