Shure PA821BX 8-Channel Antenna Combiner for PSM Wireless Systems - 865-960 Mhz
Model PA821BX
Price on Request
Availability: In Stock
- Authorized Shure Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
Shure PA821BX 8-Channel Antenna Combiner for PSM Wireless Systems - 865-960 Megahertz
The PA821B active broadband antenna combiner streamlines the simultaneous operation of many PSM systems at a venue. The PA821B combines the RF outputs from up to eight PSM transmitters into one RF output to feed a single transmit antenna. This provides significantly improved reception quality due to reduced intermodulation distortion and dropouts due to multipath interference.
The PA821B is compatible with the wireless personal monitors Shure PSM 300, PSM 900 and PSM 1000.
Why this product
Key Benefits
-
Combines up to eight PSM transmitters to a single antenna set for improved RF networking & reduced rack clutter
-
Wideband operation (470-865 MHz)
-
Quieter fan for significant reductions in ambient unit noise - especially useful for installation work
-
Temperature-sensitive fan power for significant reductions in ambient unit heat
-
8 Input LED Signals (green when active; off when inactive)
-
LED indications of signal presence, signal overload
Technical details
Technical Specifications
Wireless
- RF Gain
- 0 dB (±2 dB)
- RF Expansion Port Normal Operating Range
- 33 dBm (2 W)
Connectivity
- Impedance
- 50 Ω
- Connector Type
- BNC
Power
- Power Requirements
- 100 to 240 V AC, 50-60 Hz
- Current Drain
- 1.59 A (referenced at 100 V AC) (159 VA)
- Power Consumption
- 143 W max.
Physical
- LED Indicator Min. Detection Threshold
- 2.5 dBm
- LED Indicator Overload Threshold
- >24 dBm
Environmental
- Operating Temperature Range
- −18 °C (0 °F) to 63 °C (145 °F)
General
- PA821BX
- 865-960 MHz
- Configuration
- Active
- Configuration
- Passive
More details
Additional Information
Specifications:
- RF Frequency Range:
- RF Input:
- Main Output:
- Expansion Port:
- Insertion Loss:
