Shure QLXD1 Bodypack Transmitter - X52 Band
Model QLXD1-X52
Price on Request
Availability: In Stock
- Authorized Shure Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
Shure QLXD1 Bodypack Transmitter - X52 Band
For capturing audio, the QLXD1 Wireless Bodypack Transmitter (902 to 928 MHz) by Shure is a good 24-bit digital audio solution. It can be used for wireless vocals and instruments in audio applications such as in presentation spaces, music venues, houses of worship, DJ setups, and more. It features a 20 Hz to 20 kHz frequency range and has over 120 dB of dynamic range. Features AES 256-bit encryption for secure transmission and up to 9 hours continuous use with two AA alkaline batteries. The QLXD1 quickly syncs with a wireless receiver over IR at the push of a button and maintains clear, uninterrupted signal over its entire 328' range. All metal construction ensures durability and with a wide selection of compatible microphones choices, this bodypack transmitter when paired with a wireless receiver, provides clear audio and gets the job done.
Why this product
Key Benefits
-
For Vocal and Instrument Applications
-
20 Hz to 20 kHz Frequency Range
-
AES 256-Bit Encryption
-
Runs on AA Alkaline Batteries
-
IR Sync Capabilities
-
Over 60 Selectable Channels
-
328' Reception Range
-
Detachable Antenna
Technical details
Technical Specifications
Microphone
- Frequency Range
- 20 Hz to 20 kHz
- Maximum Input Level 1 kHz at 1% THD
- 8.5 dBV (7.5 V pp)
Wireless
- Band
- 902 to 928 MHz
- Antenna Type
- 1/4 Wave
- Occupied Bandwidth
- <200 kHz
- Modulation Type
- Shure Proprietary Digital
Battery
- Battery Type
- Shure SB900 Rechargeable Li-Ion or AA Batteries 1.5 V
Connectivity
- Connector
- 4-Pin Male Mini Connector (TA4M)
- Impedance
- 1 MOhm
- Connector
- SMA
- Impedance
- 50 Ohms
Power
- Power
- 1 mW or 10 mW
Physical
- Housing
- Cast Aluminum
- Dimensions
- 3.38 x 2.57 x 0.92" / 86 x 65 x 23 mm
- Weight
- 4.9 oz / 138 g, without Batteries
General
- Mic Offset Range
- 0 to 21 dB (in 3 dB Steps)
- Shure SB900
- up to 10 Hours
- Alkaline
- up to 9 Hours
- Configuration
- Unbalanced
More details
Additional Information
Specifications:
- Bodypack Transmitter:
- Battery Life:
- At 10 mW:
- Audio Input:
- Preamplifier Equivalent Input Noise (EIN) System Gain Setting ≥ +20: −120 dBV, A-Weighted, Typical
- RF Output:
