Shure QLXD2/SM86 Handheld Transmitter
Model QLXD2-SM86-G50
Price on Request
Availability: In Stock
- Authorized Shure Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
Shure QLXD2/SM86 SM86 with QLXD2 Handheld Transmitter
The Shure QLXD2/SM86 is a digital handheld wireless microphone transmitter compatible with QLX-D receivers. It comes equipped with an SM86 cardioid condenser capsule that features a frequency response tailored for clear vocal reproduction. The cardioid polar pattern helps to isolate the main sound source while minimizing unwanted background noise.
The Shure QLXD2/SM86 Handheld Transmitter is available with G50, H50, V50, or X52 frequency bands.
Why this product
Key Benefits
-
For QLX-D Receivers
-
SM86 Cardioid Condenser Mic Capsule
-
Interchangeable Capsule Design
-
2560 Selectable Frequencies
-
1/10mW RF Output Power
-
Backlit LCD
-
Adjustable Gain Control
-
Secure AES-256 Encryption
-
Networked Intelligent Charging
-
9-Hr AA Batteries
Technical details
Technical Specifications
Microphone
- Gain Range
- 0 to 21 dB (3 dB Steps)
- Frequency Response
- 30 Hz to 20 kHz
- Microphone Type
- Handheld Capsule
- Sound Field
- Mono
- Capsule
- Condenser
- Polar Pattern
- Cardioid
- Frequency Range
- 50 Hz to 20 kHz
- Maximum SPL
- 147 dB SPL
- Sensitivity
- -54.5 dBV/Pa
- Dynamic Range
- 124 dB
Wireless
- RF Frequency Band
- G50 (470 to 534 MHz)
- RF Bandwidth
- 64 MHz
- Frequency Step Size
- 25 kHz
- RF Channel Scanning
- Auto-Scan
- Max Operating Range
- 330' / 100.6 m
- Latency
- < 2.9 ms
- Encryption
- AES 256
- Modulation
- Proprietary
- Transmitter Type
- Handheld
- RF Output Power
- 1 / 10 mW
- Sync Method
- IR
- Antenna
- 1x 1/4 Wave
Battery
- Approx. Battery Life
- 9 Hours (Alkaline)
Connectivity
- Sample Rate/Resolution
- 48 kHz / 24-Bit
- Audio I/O
- No
Power
- Power Requirements
- Battery
Physical
- Display & Indicators
- 1x Backlit LCD (Channel, Group, RF Output Power)
- Housing
- Aluminum
- Dimensions
- 2 x 10.1" / 51 x 256 mm
- Weight
- 12.2 oz / 347 g (without Batteries)
More details
Additional Information
Specifications:
- Transmitter:
- Battery Type:
- 2x AA (Included)
- 1x Shure SB900A (Not Included, Replaceable)
- Battery Type:
- Microphone:
