Shure TL47B/O-XLR-A TwinPlex Omnidirectional Lavalier Microphone - XLR with Accessories - Black
Model TL47B-O-XLR-A
Price on Request
Availability: In Stock
- Authorized Shure Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
Shure TL47B/O-XLR-A TwinPlex Omnidirectional Lavalier Microphone - XLR with Accessories - Black
In dialogue or monologue. Song or speech. A single word can affect the whole story. Through sweat, noise, and wear and tear, your little lavalier has an enormous job to do. Shure TwinPlex stands up to the toughest conditions to make every word a clear statement of quality. Natural audio at high or low frequency, the innovative dual-diaphragm captures the complete weight of your voice. And the capsule design maximizes effective surface area in an easy-to-conceal package. So sound suits performer, not the other way around.
No more “sweat-outs.” The superhydrophobic coating keeps perspiration from upstaging the sound. And the medical-grade cable technology flexes to fit the costume design and the demanding schedule. So your lavalier rises to the challenge, night after night.
The TwinPlex™ TL47 is available with connector options for most bodypack transmitters, color options that meet numerous situational needs, and mounting choices for all professional applications. The low sensitivity can handle the most critical acoustic environments without distortion, and the 1.6 mm paintable cable stands up to the most demanding use. With extensive solutions for any application, it’s the go-to line for flexibility.
Why this product
Key Benefits
-
With a variety of colors and connectors, the TL47 is ideal for nearly any application
-
Twice the surface area of other subminiature microphones for pristine, natural response and robust low-frequency response due to the patent pending dual-diaphragm design
-
Improved off-axis consistency yields accurate reproduction regardless of vocal source position or movement
-
Best-in-class low self-noise and dynamic range for cleaner audio production
-
Interchangeable sweat- and moisture-resistant frequency caps prevent sweat-outs due to an invisible syperhydrophobic nanoscopic coating
-
Paintable 1.6 mm cable that is immune to memory effect and kinks
-
Dual redundant ground in cable serves as secondary shield for longevity
-
Sound signature: Natural
-
Sensitivity: Low
-
Colors: Black
Technical details
Technical Specifications
Microphone
- Microphone Capsule
- Dual-Diaphragm, Pre-polarized Condenser
- Polar Pattern
- Omnidirectional
- Frequency Response
- 20 Hz to 20 kHz
- Sensitivity
- -37.0 dBV(14.1 mV) at 1 kHz
- Signal-To-Noise Ratio
- 70.0 dB
- Maximum SPL
- 134.0 dB SPL - 1 kHz at 1% THD, typical
- Dynamic Range
- 110.0 dB, typical
Connectivity
- Output Clipping Level
- 3.0 dBV,1 kHz at 1% THD, typical
- Connector Polarity
- Positive pressure at diaphragm leads to positive voltage with respect to ground
- Cable Length
- 66" (1.67m)
Power
- Microphone Current Draw
- 120 to 240 µA, typical
Physical
- Housing
- Molded ABS
- Microphone Length
- 13.5mm
- Microphone Diameter
- 5.6mm
- Net Weight with Cable
- 0.42 oz. (12.0 g)
More details
Additional Information
Specifications:
- Self-Noise, A-Weighted, Equivalent Acoustical: 24.0 dB SPL-A
- Bias Voltage, Recommended Operating Voltage: 5 VDC
- Cable Diameter 1.6mm
