Shure UA844 Plus V Antenna Distribution System
Model UA844-PLUS-V
Price on Request
Availability: In Stock
- Authorized Shure Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
Shure UA844+V Antenna Distribution System
The Shure Model UA844+V is an antenna distribution system that allows for the expansion of wireless microphone systems by splitting one pair of antennas to multiple receivers. It also amplifies RF signals to compensate for insertion loss that results from splitting signal power to multiple outputs. A single UA844+V system can support up to five wireless receivers. A maximum of five UA844+V systems may be used in a two-tiered configuration. It is recommended for use with VHF options of ULX-D® Digital and QLX-D® Digital Wireless Systems.
Why this product
Key Benefits
-
Five-way RF signal output
-
Supports VHF QLX-D and ULX-D receivers
-
Front-mounting antenna hardware
-
Rack-mounting hardware
-
4 DC power feeds and for receivers (15V, 2.5A max)
-
DC outputs for antenna bias (12V, 300mA max)
More details
Additional Information
UA844+V models include:
- 1 UA844+ Antenna/Power Distribution System
- 1 PS45 power supply
- Two 6 ft. BNC cables
- 2 Bulkhead adapters
- 1 Rack mount Hardware kit
- 1 Literature Package
- 4 Locking DC power cables for ULXD4
- 4 Non-locking DC power cables for QLXD4
- Ten 22 in. BNC cables
