Yealink MeetingBar A40 Dual-Camera Android Video Bar
MPN A40
Price on Request
Availability: Contact Us
Call an Expert: +971 56 498 8088 info@corporateav.ae
- Camera system: Two 48 MP sensors; up to 4K output, subject to platform and selected mode
- Field of view: 120° diagonal; 110° horizontal; 54° vertical
- Framing: IntelliFocus, auto framing and speaker tracking; availability depends on platform and firmware
- Microphones: Built-in eight-MEMS array; published pickup up to 6 m, with 4 m high-quality pickup reference
- Audio: Built-in 2 × 10 W rated speakers; echo cancellation and noise suppression
- Authorized Yealink Reseller
- Manufacturer Warranty
- Fast UAE Delivery
- Expert Project Support
Delivery, Warranty, Returns and Installation
- Delivery
- Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
- Warranty
- Manufacturer Warranty with Local UAE Support where applicable.
- Returns
- B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
- Installation
- Site Surveys, System Design and Professional Installation are available across the UAE.
Product details
Overview
What is the Yealink MeetingBar A40?
The Yealink MeetingBar A40 combines cameras, microphones, speakers and Android meeting compute in one bar for small to medium meeting rooms. Its dual-camera view and automatic framing help keep the room visible to remote participants. Specify the controller bundle, meeting platform, display and network together so the installation supports the intended room workflow. Corporate AV can help specify the equipment and setup for projects in Dubai, Abu Dhabi and across the UAE.
An all-in-one Android collaboration bar with two 48 MP camera sensors, an eight-MEMS microphone array and stereo speakers. It supports platform-specific Teams Rooms, Zoom Rooms and compatible BYOD workflows; confirm the edition, firmware, accounts and licences required for the chosen deployment. Sensor pixel count is not the transmitted meeting resolution.
Why this product
Key Benefits
-
Camera system
Two 48 MP sensors; up to 4K output, subject to platform and selected mode.
-
Framing
IntelliFocus, auto framing and speaker tracking; availability depends on platform and firmware.
-
Microphones
Built-in eight-MEMS array; published pickup up to 6 m, with 4 m high-quality pickup reference.
-
Audio
Built-in 2 × 10 W rated speakers; echo cancellation and noise suppression.
Use cases
Applications
-
Small to medium Teams Rooms or Zoom Rooms with the appropriate edition and licences
-
Hybrid meeting rooms needing integrated camera and room audio
-
Business collaboration spaces with an assessed controller and sharing workflow
Technical details
Technical Specifications
Camera
- Camera system
- Two 48 MP sensors; up to 4K output, subject to platform and selected mode
- Field of view
- 120° diagonal; 110° horizontal; 54° vertical
- Framing
- IntelliFocus, auto framing and speaker tracking; availability depends on platform and firmware
- Field of view
- 120° diagonal; 110° horizontal; 54° vertical.
Audio
- Microphones
- Built-in eight-MEMS array; published pickup up to 6 m, with 4 m high-quality pickup reference
- Audio
- Built-in 2 × 10 W rated speakers; echo cancellation and noise suppression
Platform & Certification
- Platform
- Android 13 on Microsoft MDEP in the reference; confirm current approved firmware
Connectivity
- Display connection
- Two HDMI outputs; supported resolution depends on platform and mode
- Network
- Gigabit Ethernet and Wi-Fi 6
Physical & Power
- Dimensions (W × D × H)
- 650 × 62 × 80 mm
Shipping & Packaging
- Controller packages
- A40-010 includes VCR11; A40-031 includes CTP25 package; confirm the ordered bundle
Model & Identification
- Model
- MeetingBar A40
- Manufacturer part number
- A40
In the box
What's Included
-
One Yealink MeetingBar A40
-
Power adapter with 3.5 m lead in the reference pack
-
Two 1.8 m HDMI cables
-
One 3 m network cable
-
TV-clip mounting accessory for the bar
-
Wall mounting accessory for the bar
-
Cable cover
-
Quick start guide
Installation
Installation & Mounting
Recommended Compatible Equipment
LG 55UH5Q 55-inch 4K UHD Signage Display. Optional LG 55UH5Q 55-inch 4K display for the bar's HDMI output. Choose the screen around viewing distance and readable content; confirm HDMI timing, control and the selected meeting-platform layout. Specify a matched VSYS display mount or cart separately.
LG 65UH5Q 65-inch 4K UHD Signage Display. Optional LG 65UH5Q 65-inch 4K display where a larger image suits the seating layout. Connect by HDMI and verify display mode, CEC requirements and port access. Mount and floor-stand selection must match the display's VESA pattern and full installed load.
Installation
Confirm whether the quotation is for the base bar, A40-010 remote bundle or A40-031 CTP25 console bundle; a touch console is not implied by this generic listing. Validate the selected platform, room licence, network access, approved firmware and any BYOD sharing accessories. Position the bar with a clear view and test pickup in the actual room acoustics. Use VSYS for any separately specified display wall mount or floor stand, matched to the chosen display's screen size, VESA pattern and full load. The bar's manufacturer mounting accessories are distinct from a display support.
Ownership and support
Ownership & Support
Warranty
Confirm the applicable UAE warranty, regional SKU and service arrangements on the quotation.
Support
Share your MeetingBar A40 quantity, connected equipment and UAE project location with Corporate AV for a quotation covering the required accessories and setup.
