Bose ArenaMatch AMWG4060 60° Horizontal Waveguide for AM40 Array Module

Model AMWG4060MPN 808667-3810

Price on Request

Availability: In Stock

WhatsApp an Expert

Call an Expert: +971 56 498 8088 info@corporateav.ae

  • 60° horizontal waveguide for the ArenaMatch AM40 module
  • Gives the AM40 a 60° x 40° coverage pattern (AM40/60)
  • AM40/60: 127 dB calculated maximum SPL at 1 m (passive)
  • Swappable with the 80° and 100° waveguides to change coverage on site
Boardrooms & Meeting Rooms Part of our complete AV solutions Explore Solutions
Bose ArenaMatch AMWG4060 60° waveguide
  • Authorized Bose Reseller
  • Manufacturer Warranty
  • Fast UAE Delivery
  • Expert Project Support
Delivery, Warranty, Returns and Installation
Delivery
Fast UAE Delivery: Same-Day or Next-Day Delivery Available, Subject to Product Availability and Location. Free Delivery on Orders Above AED 2,000.
Warranty
Manufacturer Warranty with Local UAE Support where applicable.
Returns
B2B Orders are non-returnable. Please confirm product specifications and compatibility before ordering.
Installation
Site Surveys, System Design and Professional Installation are available across the UAE.
Call

Product details

Overview

What is the Bose ArenaMatch AMWG4060?

The Bose ArenaMatch AMWG4060 waveguide is a 60° horizontal waveguide for the ArenaMatch AM40 DeltaQ array module. Fitted to the AM40, which has 40° vertical coverage, it creates a 60° x 40° pattern, so the coverage of a module can be changed without replacing the loudspeaker. It is made for integrators and sound designers working on stadium, arena and outdoor venue systems in the UAE.

The Bose ArenaMatch AMWG4060 is the 60° horizontal waveguide for the ArenaMatch AM40 module, the narrowest of the 60°, 80° and 100° options Bose lists for it. With it fitted, the module has the same 60° x 40° coverage as the AM40/60 version.

Why this product

Key Benefits

  • Narrowest horizontal option

    At 60°, the AMWG4060 gives the AM40 the narrowest of its three horizontal patterns, keeping sound on a narrow audience area.

  • Highest output of the three versions

    Bose lists the AM40/60 with the highest calculated passive SPL and sensitivity of the three AM40 coverage versions.

  • Replaceable waveguides

    Bose designs the ArenaMatch AM40 so that its horizontal coverage can be changed by swapping between 60°, 80° and 100° waveguides.

  • Asymmetrical array patterns

    Mixing waveguides lets designers customise coverage module by module and form asymmetrical patterns in left and right arrays.

Use cases

Applications

  • Stadium and arena arrays

    Sets the horizontal coverage of AM40 modules to match the width of the seating area each module serves.

  • Point-source systems

    Bose recommends 40° modules such as the AM40 for point-source applications, and the 60° waveguide sets the horizontal width of that single source.

  • Outdoor hospitality and dining venues

    Adapts AM40 modules at outdoor restaurants, bars and entertainment areas to the shape of the audience area.

  • Places of worship and educational sports complexes

    Bose lists both among the ArenaMatch applications, and the waveguide lets one AM40 model suit narrow and wide zones.

Technical details

Technical Specifications

Compatibility

Compatible Models
Bose ArenaMatch AM40 DeltaQ array module

Audio Performance

Horizontal Coverage
60°
Vertical Coverage
40° (set by the AM40 module)
Coverage Pattern
60° x 40° (AM40/60)
Maximum SPL
127 dB at 1 m, passive (AM40/60, calculated)
Sensitivity
98 dB SPL, 1 W at 1 m, passive (AM40/60)

Model & Identification

Model
AMWG4060

In the box

What's Included

  • Bose AMWG4060 waveguide accessory set

Installation

Installation & Mounting

Recommended Loudspeaker Modules

The AMWG4060 fits the Bose ArenaMatch AM40 with 80° waveguide and the Bose ArenaMatch AM40 with 100° waveguide, changing either into a 60° x 40° module.

For new projects that need 60° coverage from the start, choose the Bose ArenaMatch AM40 with 60° waveguide, which already has this horizontal pattern, so a separate AMWG4060 is only needed to change the coverage of modules on site.

Installation

Bose publishes an AMWG Installation Guide for the ArenaMatch waveguides under User Documentation on the AM40 product page. Follow that guide for the fitting steps.

Ownership and support

Ownership & Support

Support

For a UAE project quotation, provide the exact model, quantity, installation location and associated equipment. Corporate AV can review the proposed system scope; confirm delivery timing, regional warranty and any separately supplied accessories on the quotation.

Complete your solution

Recommended Accessories

Expert FAQs

What does the Bose ArenaMatch AMWG4060 waveguide do?

The Bose ArenaMatch AMWG4060 waveguide sets the horizontal coverage of an ArenaMatch AM40 module to 60°. Combined with the 40° vertical coverage of the AM40, the module then has a 60° x 40° pattern, the same as the AM40/60 version.

Which loudspeaker is the AMWG4060 for?

The Bose AMWG4060 is the 60° horizontal waveguide for the ArenaMatch AM40 DeltaQ array module. Bose lists 60°, 80° and 100° horizontal versions for the AM40, so match the waveguide to the module it will be fitted to.

How loud is an AM40 fitted with the 60° waveguide?

The Bose ArenaMatch AM40/60 has a calculated maximum SPL at 1 m of 127 dB in passive mode, or 122 dB (LF) and 125 dB (HF) when bi-amped. Its sensitivity is 98 dB at 1 W, 1 m in passive mode, or 94 dB (LF) and 103 dB (HF).

Can the AMWG4060 be changed on an installed AM40?

Yes. The Bose ArenaMatch AMWG4060 is the 60° option among the swappable 60°, 80° and 100° waveguides that Bose lists for changing the AM40 horizontal coverage. The fitting steps are in the AMWG Installation Guide listed under User Documentation on the Bose Professional AM40 page.

Can I use different waveguides in the same ArenaMatch array?

Yes. The Bose ArenaMatch AMWG4060 can be combined with other ArenaMatch waveguides in one array, to customise coverage module by module and to form asymmetrical patterns in left and right arrays.

Does the AMWG4060 change amplifier power or replace the AM40 loudspeaker?

No. The AMWG4060 is a mechanical waveguide accessory that changes the horizontal sound coverage of the compatible AM40 module. It is not a powered speaker or amplifier. The host loudspeaker still needs a correctly specified external amplifier, DSP preset and system design.
